| Model No. | FGPCS-250K/0.4-0.4 | FGPCS-500K/0.4-0.4 |
| DC parameters | ||
| Max DC input voltage | 900V | |
| DC input voltage range | 600~900V | |
| Max DC input current | 566A | 1125A |
| DC input channels | 1 | |
| AC parameters (On-Grid) | ||
| Rated AC power | 250kVA | 500kVA |
| Max AC power | 275kVA | 550kVA |
| Max AC current | 397A | 794A |
| Rated AC voltage | 400V | |
| AC voltage range | 340~440V | |
| Rated frequency range | 50Hz, 45~55Hz | |
| AC THDi | <3%(Full load) | |
| Power factor | ＞0.99(Full load) | |
| Reactive power adjustment | -1~+1 | |
| AC parameters (Off-Grid) | ||
| Rated AC voltage | 400V | |
| AC voltage range | 340~440V | |
| AC THDv | <3%(Linear load) | |
| Rated frequency range | 50Hz, 45~55Hz | |
| System parameters | ||
| Isolation type | Transformer isolated | |
| Max efficiency | 96% | 97.3% |
| Protection degree | IP20 | |
| Running temperature | -30~+60℃(>45℃ derating) | |
| Allowable humidity | 0~95% | |
| Altitude | 5000m(>2000m derating) | |
| Cooling mode | Intelligent forced air cooling | |
| Communication | RS485、CAN、Ethernet | |
| Dimension(W*H*D) | 1070*2150*870mm | 1470*2150*1070mm |
| Weight | 1450kg | 2050kg |
